Aluminum L Series Rivet Nuts (Ribbed)

"L" Series Ribbed Large Flange Thin Wall Rivet Nuts

Aluminum L Series rivet nuts provide everything you need to accomplish numerous types of riveting tasks. These threaded inserts are ideal for non-magnetic applications, as well as for those that require advanced corrosion resistance. Aluminum rivnuts also provide superior strength within a lightweight bodied structure, which makes them perfect for applications that require every ounce to be accounted for. In addition, the splined body and large flange structure of these aluminum threaded inserts allows for increased torque and a larger bearing surface, which helps to improve push-out performance.

Jay-Cee Sales & Rivet, Inc. provides aluminum L Series rivet nuts in various dimensions, depending on your specific project needs. These unique aluminum rivnuts feature increased torque strength, extended wide grip range, and can be installed into areas where corrosion or metals with magnetic properties may pose an issue. These advantages along with a simple, no-hassle installation process, can save significant time and hassle over other installation processes. At Jay-Cee Sales & Rivet we are your premium aluminum rivet nuts suppliers. We provide you with advanced quality aluminum rivnuts at the industry’s most competitive prices.

Ribbed

Material:  Aluminum
Finish:
 Clear Protective Coating



U.S. Measure

THREAD

GRIP RANGE

BODY DIA

HEAD DIA

LENGTH

HOLE SIZE

PART NUMBERS

SIZE



max

+/- .010

* +/- .025

+/-.015

+.006/-.000

RN632080ALR

6-32 UNC

.020-.080

.265

0.390

0.420

.266

RN632130ALR

6-32 UNC

.080-.130

.265

0.390

0.470

.266

RN832080ALR

8-32 UNC

.020-.080

.265

0.390

0.420

.266

RN832130ALR

8-32 UNC

.080-.130

.265

0.390

0.470

.266

RN1024130ALR

10-24 UNC

.020-.130

.296

0.415

0.475

.297

RN1024225ALR

10-24 UNC

.130-.225

.296

0.415

0.585

.297

RN1032130ALR

10-32 UNF

.020-.130

.296

0.415

0.475

.297

RN1032225ALR

10-32 UNF

.130-.225

.296

0.415

0.585

.297

RN2520165ALR

1/4-20 UNC

.027-.165

.390

0.500

0.580

.391

RN2520260ALR

1/4-20 UNC

.165-.260

.390

0.500

0.680

.391

RN5161815ALR

5/16-18 UNC


Contact us for more information regarding our advanced quality aluminum L Series rivet nut options. You can also request a quote for an in-depth price analysis on any of our threaded insert products. For applications that require the use of a rivet that can be used to join or fasten leather, nylone, denim or other types of materials, we also offer compression rivets in numerous materials, sizes and styles.

Click to Filter Your Results

Advanced Quality Benefits of Aluminum L Series Rivet Nuts

Aluminum rivnuts provide a bevy of beneficial qualities that make them highly useful for a wide range of applications. If weight is a concern within your project’s scope, our aluminum threaded inserts provide nearly as much strength as steel at a fraction of the weight. Aluminum is also naturally corrosion resistant, making these aluminum rivnuts extremely useful in environments that can become damp. Some of the other benefits associated with L Series rivet nuts, include:
  • Wide Grip Range: The range of product within the L series provides a placing capability in material thickness ranging from .020" (0,5mm) to 0.312" (7,9mm).
  • Lead-In Chamfer: The lead-in chamfer on the body provides ease of insertion into the work piece.
  • High-Strength Threads: The threads are rolled into the product creating a work-hardened surface providing high-strength, load-bearing threads.
  • Splined Body: The splined body provides increased torque-to-turn resistance over conventional non-splined inserts.
  • Large Flange: Provides a large bearing surface which increases push-out performance.
As an added benefit, the aluminum L Series rivet nuts are available in a wide range of sizes and styles for your specific project needs.

Aluminum Rivet Nut Options

At Jay-Cee Sales & Rivet we offer aluminum threaded inserts in numerous lengths and diameters, depending on your specific needs. Glance at our aluminum L Series rivet nut options below for the rivnut that will perfectly suit your project needs.

Thread Size

  • 6-32
  • 8-32
  • 10-24
  • 10-32
  • 1/4-20
  • 5/16-18
  • 3/8-16
  • M10-1.5 thru M5-.80

Grip Range

  • Minimum: 0.050-2.00mm
  • Maximum: 4.20-6.60mm

Length

  • Minimum: 0.420
  • Maximum: 20.45

Contact Jay-Cee Sales & Rivet for Aluminum L Series Rivet Nuts Today

Contact us for more information regarding our aluminum rivnut options, or other styles of rivets and fastener products. For in-depth pricing information you can also request a quote on our aluminum L Series rivet nuts today.
