Stainless Steel K Series Rivet Nuts (Ribbed)

  • Ribbed
Click image to enlarge
The K Series Stainless Steel Rivet Nuts is manufactured from advanced quality stainless steel and features United Screw Thread Series UNC and UNF thread styles. These premium ribbed rivet nuts provide numerous features including advanced strength, splined or non-splined body and a small or large flange head. Ribbed L Series rivet nuts are generally used for marine, industrial and architectural applications.

As your premium stainless steel rivet nut suppliers, Jay-Cee Sales & Rivet offers our stainless steel rivet nuts in a wide variety of diameters, lengths, and thread sizes. These advanced quality fasteners can be installed in quickly and easily from a single side of the work material. Ribbed K Series rivet nuts provide initial fastening services with the added benefit of internal threading attachments. At Jay-Cee Sales & Rivet we are your respected and trusted K Series ribbed rivet nuts supplier. We provide you with advanced quality stainless steel rivet nuts at prices that can’t be beat.

Ribbed



Material:  18-8 Stainless Steel



U.S. Measurement

THREAD

GRIP RANGE

BODY DIA

HEAD DIA

LENGTH

HOLE SIZE

PART NUMBERS

SIZE



MAX

+/- .010

* +/- .025

+-/ .015

+.006/-.000

RN632080FKR

6-32 UNC

.020-.080

.265

0.310

0.420

0.266

RN632130FKR

6-32 UNC

.080-.130

.265

0.310

0.470

0.266

RN832080FKR

8-32 UNC

.020-.080

.265

0.310

0.420

0.266

RN832130FKR

8-32 UNC

.080-.130

.265

0.310

0.470

0.266

RN1024130FKR

10-24 UNC

.020-.130

.296

0.340

0.475

0.297

RN1024225FKR

10-24 UNC

.130-.225

.296

0.340

0.585

0.297

RN1032130FKR

10-32 UNF

.020-.130

.296

0.340

0.475

0.297

RN1032225FKR

10-32 UNF

.130-.225

.296

0.340

0.585

0.297

RN2520165FKR

1/4-20 UNC

.027-.165

.390

0.455

0.580

0.391

RN2520260FKR

1/4-20 UNC

.165-.260

.390

0.455

0.680

0.391

RN5161815FKR

5/16-18 UNC

.027-.150

.530

0.595

0.690

0.531

RN5161831FKR

5/16-18 UNC

.150-.312

.530

0.595

0.805

0.531

RN3816150FKR

3/8-16 UNC

.027-.150

.530

0.595

0.690

0.531

RN3816312FKR

3/8-16 UNC

.150-.312

.530

0.595

0.805

0.531


Contact us for more information regarding our stainless steel K Series rivet nut options. You can also request a quote for an in-depth price analysis on any of our stainless steel rivet product options. For light fixture, HVAC duct, ladder, brake or electronic applications, we also offer semi-tubular rivets in a wide range of sizes and styles.



Ribbed K Series Rivet Nut Advantages

Jay-cee Sales & Rivet’s K Series ribbed rivet nuts provide a wide range of benefits that can be used for numerous industrial applications. Some of the main advantages of stainless steel K Series rivet nuts, include:
  • High-Strength Threads: The threads are rolled into the product creating a work-hardened surface providing high-strength, load-bearing threads.
  • Splined Body: The splined body provides increased torque-to-turn resistance over conventional non-splined inserts.
  • Lead-In Chamfer: The lead-in chamfer on the body provides ease of insertion into the work piece.
  • Wide Grip Range: The range of product within the K series provides a placing capability in material thickness ranging from .020" (0,5mm) to 0.312" (7,9mm).
  • Near-Flush Installation: The low-profile head provides near-flush seating without special hole preparation.

Stainless Steel K Series Rivet Nut Options

Stainless steel rivet nuts provide a complete total fastening system that allows for secure fastening and attaching via the rivets internal threads. Our stainless steel rivet nuts provide all the requirements that are necessary for all types of applications. For more information on our rivet nut options you can view our rivet identification chart to learn more about the features and benefits of our riv nut products. Our stainless steel K Series ribbed rivet nuts are available with the following options:

Thread Size

  • 6-32
  • 8-32
  • 10-24
  • 10-32
  • 1/4-20
  • 3/8-16
  • M10-1.5
  • M6-1.0
  • M8-1.25
  • M4-.70
  • M5-.80

Grip Range

  • Minimum: 0.50-2.00mm
  • Maximum: 4.20-6.60mm

Length

  • Minimum: 0.420
  • Maximum: 20.45

Contact Jay-Cee Sales & Rivet for Ribbed K Series Rivet Nuts Today

Contact us for more information regarding our stainless steel rivet nut options, or other styles of rivets and fastener products. If you have questions regarding any of our fastener products feel free to call us at 888-JC-RIVET today.
