Large Flange Head

Aluminum rivet with Aluminum Mandrel Dome Head

View larger image


Aluminum body blind rivets with an aluminum mandrel.



            DOME HEAD               LARGE FLANGE                120' C'SUNK

Values in green are metric

Rivet
Series
Number
Nominal
Rivet
Size
(D)
Body Diameter

Large Flange Head

Hole Size
and
Drill
Number
Max. Min. (A)
Head
Dia.
(H)
Max
Head
Hgt.

3

3/32 (2.4mm)

0.096

0.090

0.281

0.040

.097-100(#41)

4

1/8 (3.2mm)

0.128

0.122

0.375

0.065

.129-.133(#30)

5

5/32 (4.0mm)

0.159

0.153

0.469

0.075

.160-.164(#20)

6

3/16 (4.8mm)

0.191

0.183

0.625

0.092

.192-.196(#11)

8

1/4 (6.4mm)

0.255

0.246

0.750

0.107

.257-.261 (F)

Length varies with each grip length, click for spec page


Values in green are metric

Rivet
Diameter
G
Grip
Range
L
Rivet
Lengths
Max
Aluminum Rivet
Aluminum Mandrel
IFI Grade 11
Dome
Head
S
H
E
A
R
T
E
N
S
I
L
E
Body Diameter
3/32 (2.4mm)
.020-.125
(0.8-3.2mm)
.250
(6.4mm)
PR32AAL 70 80
.126-.250
(3.3-6.4mm)
.375
(9.5mm)
PR34AAL
.251-.375 .500 PR36AAL
Body Diameter 1/8 (3.2mm) GRIP RANGE .020-.062
(0.8-1.6mm)
MAX LENGTH .212
(5.4mm)
PR41AAL 120 150
.063-.125
(1.7-3.2mm)
.275
(7.0mm)
PR42AAL
.126-.187
(3.3-4.8mm)
.337
(8.6mm)
PR43AAL
.188-.250
(4.9-6.4mm)
.400
(10.2mm)
PR44AAL
.251-.312
(6.5-7.9mm)
.462
(11.7mm)
PR45AAL
.313-.375
(8.0-9.5mm)
.525
(13.4mm)
PR46AAL
.376-.500
(9.6-12.7mm)
.650
(16.5mm)
PR48AAL
.501-.625
(12.8-15.9mm)
.775
(19.7mm)
PR410AAL
Body Diameter
5/32 (4.0mm)
GRIP RANGE .020-.125
(1.6-3.2mm)
MAX LENGTH .300
(7.6mm)
PR52AAL 190 230
.126-.187
(3.3-4.8mm)
.362
(9.2mm)
PR53AAL
.188-.250
(4.9-6.4mm)
.425
(10.8mm)
PR54AAL
.251-.375
(6.5-9.5mm)
.550
(14.0mm)
PR56AAL
.376-.500
(9.6-12.7mm)
.675
(17.2mm)
PR58AAL
.501-.625
(12.7-17.1mm)
.800
(20.3mm)
PR510AAL
Body Diameter
3/16 (4.8mm)
GRIP RANGE .020-.125
(1.6-3.2mm)
MAX LENGTH .325
(8.3mm)
PR62AAL 260 320
.125-.250
(3.2-6.4mm)
.450
(11.5mm)
PR64AAL
.251-.375
(6.5-9.5mm)
.575
(14.6mm)
PR66AAL
.376-.500
(9.6-12.7mm)
.700
(17.8mm)
PR68AAL
.501-.625
(12.8-15.9mm)
.825
(21.0mm)
PR610AAL
.626-.750
(16.0-19.1mm)
.950
(24.2mm)
PR612AAL
.751-.875
(19.1-22.2mm)
1.075
(27.3mm)
PR614AAL
.876-1.000
(22.3-25.4mm)
1.200
(30.5mm)
PR616AAL
Body Diameter
1/4 (6.4mm)
GRIP RANGE .020-.125
(1.6-3.2mm)
MAX LENGTH .375
(9.52mm)
PR82AAL 460 560
.126-.250
(3.3-6.4mm)
.500
(12.7mm)
PR84AAL
.251-.375
(6.5-9.5mm)
.625
(15.9mm)
PR86AAL
.376-.500
(9.6-12.7mm)
.750
(19.1mm)
PR88AAL
.501-.625
(12.8-15.9mm)
.875
(21.0mm)
PR810AAL
.626-.750
(16.0-19.1mm)
1.000
(25.4mm)
PR812AAL
.751-.875
(19.1-22.2mm)
1.125
(28.6mm)
PR814AAL
.876-1.000
(22.3-25.4mm)
1.250
(31.8mm)
PR816AAL
